Pictured above is a diagram of a SMART Board

This book is a basic guide to SMART Boards and

includes the following:

-How to Turn on the SMART Board

-How To Connect a Computer to a SMART Board

-How To Calibrate the Projector

-How To Change Pen Color and Use the Eraser

There are also pictures and diagrams of the SMART

Board.

How To Turn On the SMART Board

1. Push the 'On' button on the

projector. It is located near the center

of the projector.

2. Push the 'On' button on the SMART

Board. It is located on the left side of

the board.

3. Turn on the computer.

4. Once the SMART Board is on, make

sure the computer is correctly

connected.

Pictured right is a student turning on

the projector.

Pictured left is a student turning on the

SMART Board.

How To Connect a Computer To

the SMART Board

1. Using the VGA cable, insert the VGA cable into the computer port. The VGA cable

is a thick, black cable with blue ends. It has two screws on each end. The other end

of the VGA cable should be connected to the projector. If it is not connected,

connect the VGA cable into the necessary port.

2. Once both ends of the VGA cable are inserted, the computer's screen should

shown on the SmartBoard. If not, unplug the VGA cable from the computer and try

again.

Pictured left is a VGA cable. Note that both ends

are blue and both have screws to secure the

cable to the computer.

Pictured above is a computer connected to the SMART Board with a VGA

cable. This computer has a VGA adapter because Mac computers do not

have VGA ports.

How To Calibrate the SMART

Board and Projector

1. On the SMART Board chalk tray, push the

calibrate button. It is a circle button with a

diamond shape printed on it and to the

right of the Power Button.

2. Once the button is pushed, the SMART

Board screen with be gray and have a red

cross, as shown on the left.

3. Push the center of the red cross for each

highlighted diamond shape.

4. Continue pushing each red cross until

finished.

5. The SMART Board and projector are now

calibrated.

Pictured right is a student pushing the

Calibrate button.

Pictured above is what the SMART Board will look like after the Calibrate button has

been pushed. Note the red cross and the faint circles.
